MOBILE

MOBILE

  • parallel-moving crimping movement, tested for 20,000 cycles
  • 10,000 kN of crimping force
  • change crimping dies in one operation - quick and easy
  • the crimping dies are always kept together in pairs and are stored in custom holders
  • wide selection of crimping dies allows you to use all applications in a tool frame

Mechanical crimping tool (frame only). Associated dies purchased separately. Choose from around 20 associated dies.

    Add to cart Create product leaflet
    Item number: 5119-310500
    EAN: 7393487036635

    AWG/MCM Cu: 24 - 8 AWG
    mm² Cu: 0,25-10
    Suitable for: Various applications
    Construction/operation: Mechanic
    Compression shape: Universal (exchangeable inserts)
    With locking device (for mechanical tools): Yes
    Cross section, Min (mm²): 0.25
    Cross section, Max (mm²): 10
    AWG-range, Min: 24
    AWG-range, Max: 8
    With automatic return: Yes
    Inserts exchangeable: Yes
    Cycle time, Min (s): 10
    Compression force, Min (kN): 10
    Compression force, Max (kN): 10
    Length (mm): 234
    Pieces per pack: 1

    Net weight (kg): 0.554
    Height Pack (mm): 33
    Depth Pack (mm): 335
    Width Pack (mm): 160
