C-sleeves 6-300 mm²

C95-120

  • Material: Cu 99.95%.
  • Unique patented solution.
  • Possible to front feed all branches.

Example of marking: 25-185/175-240 Area min-max / Tot. area min-max

Elpress logotype BC15 Die pair BC15

Branching sleeve for splicing and branching earth lines as well as lightning control installations. Used with Elpress certified systems V1300, V250.

  • REACH
  • RoHS
  • SYSELP
  • CE
  • UKCA
Add to cart Create product leaflet
Item number: 7309-300800
EAN: 7393487062924

a (mm): 45
b (mm): 35
c (mm): 25.6

Max voltage (kV): 1

mm² C-sleeve Cu Range, Min: 175
mm² C-sleeve Cu Range, Max: 240
Side feed, Cu (mm²): 95/95, 120/70-120, 150/25-70, 185/25-50
Front feed, Cu (mm²): 95/95, 120/70-120, 150/25-70, 185/25-50
Side feed, Cu (AWG/MCM): 3/0 / 3/0, 4/0 / 2/0-4/0, 300MCM/#4-2/0, 350MCM/#4-1/0
Front feed, Cu (AWG/MCM): 3/0 / 3/0, 4/0 / 2/0-4/0, 300MCM/#4-2/0, 350MCM/#4-1/0



Find the right tool for your terminal in an easy way.

With the help of Elpress “Tool search” you can get information about which dies, matrixes, punches, crimp tools and pumps you can use together to make a correct crimping according to System Elpress.
