C-sleeves 6-300 mm²
Material: Cu 99.95%.
Tin plated sleeves (except C95-120, C150-185, C240-300 and C23 which are not tin plated).
For splicing and branching earth lines and other types of equipotential bonding applications.
In some cases, 2 or 3 crimps are required.
Unique patented solution based on previously patented solution for the C25-50 branching sleeve (formerly known as C89).
Possible to front feed all branches.
Name
Side feed, Cu (mm²)
Front feed, Cu (mm²)
Die nr
-
150/95-150, 185/70-185, 240/25-185, 300/25-120150/95-150, 185/70-185, 240/25-185, 300/25-120C18
